Size Range: DN40-DN300
Pressure: PN10, PN16
Temperature Range: -10℃ to 120℃
Face to Face: DIN 3202 F4, EN558-1 14
Flange Standard: EN1092-2 PN10/PN16, IS07005-2
Main Parts:
Body/Bonnet/Disc: Cast iron, Ductile iron
Sealing: Brass, Stainless steel
Stem: Stainless steel
Fasteners: Galvanized carbon steel, Stainless steel
● Excellent product appearance design.
● Low torque.
● Zero leakage is possible.
● Surface treatment can be done by epoxy coating or painting.
● With a stuffing box design, the stuffing can be replaced under pressure.
● There is a back sealing design.
● Multiple operators can be chosen, such as handwheel, keycap, actuator, and optional position indicator etc.
